Wheel Hub 515100
This 515100 wheel hub assembly from DUHUI Bearing provides a direct-fit replacement for the front axle of select Ford F-450 and F-550 Super Duty trucks manufactured between 2001 and 2004. It includes a complete hub assembly with an integrated ABS sensor and is ready for installation. This kit matches OE specifications including Ford part number 4C3Z-1104-AA and interchanges with industry-standard references such as BR930428 and HA590233.
Technical Specifications
| Specification | Value / Detail |
|---|---|
| DH Code | DWH1595 |
| Part Number | 515100 |
| Product Type | Wheel Hub Assembly |
| Installation Location | Front Axle |
| Kit Contents | Hub × 1 |
| Flange Diameter | 7.992″ / 203.00 mm |
| Bolt Circle Diameter | 6.685″ / 169.80 mm |
| Wheel Pilot Diameter | 4.910″ / 124.70 mm |
| Brake Pilot Diameter | 5.078″ / 129.00 mm |
| Flange Offset | 2.171″ / 55.10 mm |
| Hub Pilot Diameter | 4.488″ / 114.00 mm |
| Hub Bolt Circle Diameter | 5.503″ / 139.80 mm |
| Bolt Size | M14 × 2 |
| Bolt Quantity | 8 |
| Bolt Hole MET | M14 × 1.5 |
| Bolt Hole Quantity | 4 |
| ABS Sensor | With integrated ABS sensor |
The flange diameter of 7.992 inches (203.00 mm) and 8-bolt design are critical fitment specs for this heavy-duty front wheel hub assembly. This kit includes the hub with an integrated ABS sensor and is designed for Ford Super Duty F-450 and F-550 trucks.
Important: All information on this page is for reference only. Please verify OE numbers, dimensions, and vehicle fitment against your original part before ordering. Contact us for fitment confirmation.
DH Code & OE Number & Reference Numbers
DH Code:
DWH1595
OE Numbers:
4C3Z-1104-AA, 4C3Z-1104-BA, 4C3Z-1104-CA
Reference Numbers (Interchange):
BR930428
HA590233
Vehicle Fitment
FORD F-450 SUPER DUTY: 6.8L V10 – 2001–2004
FORD F-450 SUPER DUTY: 6.0L V8 Turbo Diesel – 2003–2004
FORD F-450 SUPER DUTY: 7.3L V8 Turbo Diesel – 2001–2003
FORD F-550 SUPER DUTY: 6.0L V8 Turbo Diesel – 2003–2004
Fitment note: This hub assembly fits Ford F-450 and F-550 Super Duty trucks with front axle applications. Please verify OE number, dimensions and vehicle configuration before ordering.
Product Features
- Direct OE replacement. This hub assembly matches Ford OE specifications 4C3Z-1104-AA and 4C3Z-1104-BA for Super Duty applications.
- Heavy-duty construction. Designed for Ford F-450 and F-550 Super Duty trucks, capable of handling commercial-grade loads and towing applications.
- Integrated ABS sensor. Built-in ABS sensor ensures proper anti-lock braking system functionality.
- Precision-engineered fitment. Features 203mm flange diameter and 8-bolt design for exact vehicle compatibility.
- Customization options. Product customization (Logo / Code / Pattern / Words) and packaging customization (Plastic bag / White box / Color box / Carton / Pallet) available upon request.
Installation Notes
- Verify fitment. Confirm this kit matches your original hub specifications before installation.
- Check your vehicle configuration. This hub is designed for Ford F-450 and F-550 Super Duty models. Verify your specific model, year, and engine before ordering.
- ABS sensor compatibility. This hub includes an integrated ABS sensor. Ensure proper connection during installation.
- Heavy-duty application. Proper torque specifications are critical for safe operation of commercial-grade vehicles.
- Kit contents. This kit includes one hub. Verify all components are present before installation.
- Professional installation recommended. Proper bearing installation and torque specifications are critical to prevent premature wear and wheel hub issues.
About DUHUI Bearing
Manufactured by DUHUI Bearing – an automotive bearing supplier established in Zhejiang, China, in 2003. DUHUI produces wheel hub bearings, center support bearings, and related components to OE specifications. Contact us
For fitment questions, compare your old part number against the OE numbers listed above.
