Wheel Hub 515095
This 515095 wheel bearing and hub assembly from DUHUI Bearing provides a direct-fit replacement for the front axle of select Lincoln Navigator and Ford Expedition models manufactured between 2007 and 2010 with 4WD/AWD configurations. This complete assembly is pre-greased, pre-set, and includes an integrated ABS sensor ring for simplified installation.
Technical Specifications
| Specification | Value / Detail |
|---|---|
| DH Code | DWH1590 |
| Part Number | 515095 |
| Product Type | Wheel Bearing & Hub Assembly |
| Installation Location | Front Axle |
| Kit Contents | Hub × 1 |
| Flange Diameter | 7.205″ / 183.00 mm |
| Flange Offset | 1.811″ / 46.00 mm |
| Bolt Circle Diameter | 5.315″ / 135.00 mm |
| Hub Pilot Diameter | 3.911″ / 99.30 mm |
| Wheel Pilot Diameter | 3.422″ / 86.80 mm |
| Brake Pilot Diameter | 3.543″ / 90.00 mm |
| Bolt Size | M14 × 2 |
| Wheel Stud Quantity | 6 |
| Spline Quantity | 45 |
| Flange Shape | Modified / Rectangular |
| ABS Sensor | With integrated sensor ring |
The flange diameter of 7.205 inches (183.00 mm) and 6-bolt design with 45-spline configuration are critical fitment specs for this front wheel bearing and hub assembly. This assembly is pre-assembled and features multi-lip seals for contamination resistance.
Important: All information on this page is for reference only. Please verify OE numbers, dimensions, and vehicle fitment against your original part before ordering. Contact us for fitment confirmation.
DH Code & OE Number & Reference Numbers
DH Code:
DWH1590
OE Numbers:
7L1Z-1104AA, 7L1Z-1104B, 7L1Z-1104D
Reference Numbers (Interchange):
SKF: BR930743
Moog: 515095
301763
Vehicle Fitment
LINCOLN NAVIGATOR: 2007–2010 (Front, 4WD/AWD)
LINCOLN NAVIGATOR L: 2007–2010 (Front, 4WD/AWD)
FORD EXPEDITION: 2007–2010 (Front, 4WD)
FORD EXPEDITION EL: 2007–2010 (Front, 4WD)
Fitment note: This hub assembly fits Lincoln Navigator and Ford Expedition models with 4WD/AWD front axle configurations. Please verify OE number, dimensions and vehicle configuration before ordering.
Product Features
- Direct OE replacement. This assembly matches Ford/Lincoln OE specifications 7L1Z-1104AA and 7L1Z-1104D.
- Complete front axle assembly. Includes hub with integrated sensor ring and coated wheel studs for corrosion resistance.
- Integrated ABS sensor ring. Built-in tone ring ensures proper anti-lock braking system and traction control functionality.
- Precision-engineered fitment. Features 45-spline design and 6-bolt configuration for exact vehicle compatibility.
- Maintenance-free design. Pre-set, pre-lubricated, and sealed assembly eliminates the need for repacking or adjustment.
- Customization options. Product customization (Logo / Code / Pattern / Words) and packaging customization (Plastic bag / White box / Color box / Carton / Pallet) available upon request.
Installation Notes
- Verify fitment. Confirm this assembly matches your original hub specifications before installation.
- Check your vehicle configuration. This hub is designed for Lincoln Navigator and Ford Expedition models with 4WD/AWD front axles from 2007–2010. Verify your specific model, year, and engine before ordering.
- ABS sensor compatibility. This assembly includes an integrated sensor ring. Ensure proper electrical connection during installation.
- Kit contents. This kit includes one hub assembly with pre-installed wheel studs. Verify all components are present before installation.
- Professional installation recommended. Proper bearing installation and torque specifications are critical to prevent premature wear and wheel hub issues.
About DUHUI Bearing
Manufactured by DUHUI Bearing – an automotive bearing supplier established in Zhejiang, China, in 2003. DUHUI produces wheel hub bearings, center support bearings, and related components to OE specifications. Contact us
For fitment questions, compare your old part number against the OE numbers listed above.
