Wheel Hub 515070
The 515070 wheel hub assembly from DUHUI Bearing provides a direct-fit replacement for the front axle of select Dodge Ram 3500 4WD dual rear wheel (DRW) vehicles manufactured between 1994 and 1999. This complete hub assembly is pre-assembled for simplified installation. This kit matches OE specifications including 515070, and interchanges with industry-standard references such as Timken 515070 and Moog 515070.
Technical Specifications
| Specification | Value / Detail |
|---|---|
| DH Code | DWH1565 |
| Part Number | 515070 |
| Product Type | Wheel Hub Assembly |
| Installation Location | Front Axle |
| Kit Contents | Hub × 1 |
| Flange Diameter | 208.30 mm (8.200 inch) |
| Bolt Circle Diameter | 165.10 mm (6.500 inch) |
| Wheel Pilot Diameter | 116.80 mm (4.600 inch) |
| Flange Offset | 68.60 mm (2.700 inch) |
| Hub Pilot Diameter | 114.30 mm (4.500 inch) |
| Hub Bolt Circle Diameter | 139.70 mm (5.500 inch) |
| Wheel Stud Quantity | 8 |
| Bolt Hole Quantity | 4 |
| ABS Sensor | Without sensor (Non-ABS) |
| Number of Splines | 33 |
Important: All information on this page is for reference only. Please verify OE numbers, dimensions, and vehicle fitment against your original part before ordering. Contact us for fitment confirmation.
DH Code & OE Numbers & Reference Numbers
DH Code:
DWH1565
OE Numbers:
515070
Reference Numbers (Interchange):
Timken: 515070
Moog: 515070
Vehicle Fitment
DODGE RAM 3500: 1994–1999 (4WD, 2-Wheel ABS, DRW)
Fitment note: This hub assembly is designed for 4WD dual rear wheel (DRW) applications only. Fits front axle, both driver and passenger sides. This hub is Non-ABS configuration with 2-Wheel ABS compatibility. Please verify OE number, dimensions and vehicle configuration before ordering.
Product Features
- Direct OE replacement for Dodge Ram 3500 4WD DRW applications. Matches specification 515070.
- 33-spline design provides secure axle engagement for heavy-duty applications.
- 8-lug wheel mounting pattern with 4-bolt flange attachment ensures secure installation.
- Heavy-duty construction designed for commercial-grade DRW applications.
- Pre-set, pre-lubricated, and sealed – maintenance-free design.
- Fully assembled kit – no additional components required for installation.
Installation Notes
- Verify your vehicle is 4WD with dual rear wheels (DRW) before installation. This hub is NOT compatible with SRW or 2WD applications.
- Confirm your vehicle has 2-Wheel ABS or Non-ABS configuration.
- Before installation, compare the flange diameter (208.30 mm) and spline count (33) against your original hub.
- Torque the axle nut and mounting bolts to Dodge specification.
- This hub fits both front driver and passenger sides. Sold individually.
About DUHUI Bearing
Manufactured by DUHUI Bearing – an automotive bearing supplier established in Zhejiang, China, in 2003. DUHUI produces wheel hub assemblies, center support bearings, and related components to OE specifications. Contact us
