Wheel Hub 515000
This 515000 wheel hub assembly from DUHUI Bearing provides a direct-fit replacement for the front axle of select Ford Aerostar AWD models manufactured between 1990 and 1997. This complete hub assembly includes wheel studs and is ready for installation. This kit matches OE specifications including Ford part number E99Z-1104A and interchanges with industry-standard references such as Timken 515000, SKF BR930116, and FW700.
Technical Specifications
| Specification | Value / Detail |
|---|---|
| DH Code | DWH01496 |
| Part Number | 515000 |
| Product Type | Wheel Hub Assembly |
| Installation Location | Front Axle |
| Kit Contents | Hub × 1 |
| Flange Diameter | 5.709″ / 145.00 mm |
| Bolt Circle Diameter | 4.500″ / 114.30 mm |
| Wheel Pilot Diameter | 2.520″ / 64.00 mm |
| Brake Pilot Diameter | 2.535″ / 64.40 mm |
| Flange Offset | 2.008″ / 51.00 mm |
| Hub Pilot Diameter | 3.937″ / 100.00 mm |
| Hub Bolt Circle Diameter | 4.748″ / 120.60 mm |
| Bolt Size | 1/2-20 UNF |
| Bolt Quantity | 5 |
| Bolt Hole MET | M12 × 1.75 |
| Bolt Hole Quantity | 3 |
| Flange Shape | Modified Triangle |
| ABS Sensor | No (non-ABS) |
| Number of Splines | 26 |
The flange diameter of 5.709 inches (145.00 mm) and 5-bolt design are critical fitment specs for this front wheel hub assembly. This kit includes the hub and is designed for non-ABS applications.
Important: All information on this page is for reference only. Please verify OE numbers, dimensions, and vehicle fitment against your original part before ordering. Contact us for fitment confirmation.
DH Code & OE Number & Reference Numbers
DH Code:
DWH01496
OE Numbers:
E99Z-1104A, F1TZ-1104A, F3TZ-1104A
Reference Numbers (Interchange):
Timken: 515000
SKF: BR930116
Moog: 515000
FW700
Vehicle Fitment
FORD AEROSTAR: 1990–1997 (AWD, Front Axle)
Fitment note: This hub assembly fits Ford Aerostar models with AWD front axle applications and non-ABS configurations. Please verify OE number, dimensions and vehicle configuration before ordering.
Product Features
- Direct OE replacement. This hub assembly matches Ford OE specification E99Z-1104A for Aerostar AWD applications.
- Complete front axle hub. Includes hub with pre-installed wheel studs for a full front wheel bearing replacement.
- Non-ABS configuration. Designed for vehicles without ABS.
- Precision-engineered fitment. Features modified triangle flange shape with 26-spline design for exact vehicle compatibility.
- Maintenance-free design. Pre-set, pre-lubricated, and sealed hub assembly requires no maintenance.
- Customization options. Product customization (Logo / Code / Pattern / Words) and packaging customization (Plastic bag / White box / Color box / Carton / Pallet) available upon request.
Installation Notes
- Verify fitment. Confirm this kit matches your original hub specifications before installation.
- Check your vehicle configuration. This hub is designed for Ford Aerostar models with AWD front axle applications. Verify your specific model, year, and engine before ordering.
- Non-ABS application. This hub does not include an integrated ABS sensor.
- Kit contents. This kit includes one hub. Verify all components are present before installation.
- Professional installation recommended. Proper bearing installation and torque specifications are critical to prevent premature wear and wheel hub issues.
About DUHUI Bearing
Manufactured by DUHUI Bearing – an automotive bearing supplier established in Zhejiang, China, in 2003. DUHUI produces wheel hub bearings, center support bearings, and related components to OE specifications. Contact us
For fitment questions, compare your old part number against the OE numbers listed above.
