Wheel Hub 512025
The 512025 wheel hub assembly from DUHUI Bearing provides a direct-fit replacement for the rear axle of select Nissan vehicles, including Sentra, 200SX, Sunny, and 100 NX models manufactured between 1990 and 2001. This complete hub assembly is pre-assembled for simplified installation. This kit matches OE specifications including 4320050Y00 and 43200F4330, and interchanges with industry-standard references such as SKF VKBA3202 and Timken 512025.
Technical Specifications
| Specification | Value / Detail |
|---|---|
| DH Code | DWH1024 |
| Part Number | 512025 |
| Product Type | Wheel Hub Assembly |
| Installation Location | Rear Axle |
| Kit Contents | Hub × 1 |
| Flange Diameter | 134.00 mm (5.280 inch) |
| Bolt Circle Diameter | 100.00 mm (3.940 inch) |
| Wheel Pilot Diameter | 52.00 mm (2.050 inch) |
| Brake Pilot Diameter | 52.00 mm (2.050 inch) |
| Flange Offset | 52.50 mm (2.070 inch) |
| Hub Pilot Diameter | 62.20 mm (2.450 inch) |
| Bolt Size | M12 × 1.5 |
| Bolt Quantity | 4 |
| ABS Sensor | Without sensor (Non-ABS) |
| Number of Splines | N/A |
Important: All information on this page is for reference only. Please verify OE numbers, dimensions, and vehicle fitment against your original part before ordering. Contact us for fitment confirmation.
DH Code & OE Numbers & Reference Numbers
DH Code:
DWH1024
OE Numbers:
4320050Y00, 43200F4330, 432000M001
Reference Numbers (Interchange):
Timken: 512025
SKF: VKBA3202
Vehicle Fitment
NISSAN 100 NX (B13): 1990–1996
NISSAN ALMERA (N15, SEDAN): 1995–2000
NISSAN ALMERA (N15, HATCHBACK): 1995–2001
NISSAN SUNNY (N14, SEDAN): 1990–1996
NISSAN SUNNY (Y10, WAGON): 1990–2000
NISSAN SUNNY (N14, HATCHBACK): 1990–1995
NISSAN 200SX: 1995–1998 (USA production)
NISSAN SENTRA: 1991–1999 (USA production)
All applications: Rear Axle, Non-ABS. Please verify OE number, dimensions and vehicle configuration before ordering.
Product Features
- Direct OE replacement for Nissan B13, N14, N15, and Y10 platform applications.
- Non-ABS configuration – designed for vehicles without rear ABS sensor.
- 4-bolt wheel mounting pattern provides secure attachment.
- Pre-set, pre-lubricated, and sealed – maintenance-free design.
- Fully assembled kit – no additional components required for installation.
Installation Notes
- Verify your vehicle does NOT have rear ABS before installation. This hub is Non-ABS configuration.
- Before installation, compare the flange diameter (134.00 mm) and bolt pattern against your original hub.
- For US-market Sentra (1997–1999) and 200SX (1997–1998), confirm production origin before ordering.
- Torque the axle nut and mounting bolts to Nissan specification.
- This hub fits both rear driver and passenger sides. Sold individually.
About DUHUI Bearing
Manufactured by DUHUI Bearing – an automotive bearing supplier established in Zhejiang, China, in 2003. DUHUI produces wheel hub assemblies, center support bearings, and related components to OE specifications. Contact us
