Wheel Hub 512023
The 512023 wheel hub assembly from DUHUI Bearing provides a direct-fit replacement for the rear axle of select Dodge Neon and Plymouth Neon vehicles manufactured between 1995 and 1997. This complete hub assembly includes an integrated ABS tone ring sensor and is pre-assembled for simplified installation. This kit matches OE specifications including 4509600 and 4509599, and interchanges with industry-standard references such as Timken 512023, SKF BR930196, and Moog RW823.
Technical Specifications
| Specification | Value / Detail |
|---|---|
| DH Code | DWH1022 |
| Part Number | 512023 |
| Product Type | Wheel Hub Assembly |
| Installation Location | Rear Axle |
| Kit Contents | Hub × 1 |
| Flange Diameter | 135.00 mm (5.310 inch) |
| Bolt Circle Diameter | 100.00 mm (3.940 inch) |
| Wheel Pilot Diameter | 56.90 mm (2.240 inch) |
| Brake Pilot Diameter | 57.40 mm (2.260 inch) |
| Flange Offset | 52.30 mm (2.060 inch) |
| Hub Pilot Diameter | 70.10 mm (2.760 inch) |
| Bolt Size | M12 × 1.5 |
| Bolt Quantity | 5 |
| ABS Sensor | With integrated tone ring sensor |
| Number of Splines | N/A |
Important: All information on this page is for reference only. Please verify OE numbers, dimensions, and vehicle fitment against your original part before ordering. Contact us for fitment confirmation.
DH Code & OE Numbers & Reference Numbers
DH Code:
DWH1022
OE Numbers:
4509600, 4509599
Reference Numbers (Interchange):
Timken: 512023
SKF: BR930196
Moog: RW823
Vehicle Fitment
DODGE NEON: 1995 (5-Stud Hub Assembly), 1996–1997
PLYMOUTH NEON: 1995 (5-Stud Hub Assembly), 1996–1997
All applications: Rear Axle. Please verify OE number, dimensions and vehicle configuration before ordering.
Product Features
- Direct OE replacement for Chrysler PL platform vehicles. Matches specifications 4509600 and 4509599.
- Integrated ABS tone ring sensor ensures proper anti-lock braking system function.
- 5-bolt wheel mounting pattern provides secure attachment.
- Pre-set, pre-lubricated, and sealed – maintenance-free design.
- Fully assembled kit – no additional components required for installation.
Installation Notes
- Verify your vehicle has a 5-stud hub configuration before installation. 1995 Neon models use this 5-stud assembly.
- Before installation, compare the flange diameter (135.00 mm) and bolt pattern against your original hub.
- Confirm the ABS tone ring sensor connector matches your vehicle’s harness.
- Torque the axle nut and mounting bolts to Chrysler specification.
- This hub fits both rear driver and passenger sides. Sold individually.
