3104102XGW01A Wheel Hub Bearing For Great-Wall-Haval
The DUHUI 3104102XGW01A wheel hub bearing is a direct-fit rear axle replacement designed for Haval Big Dog and Dargo models. This rear wheel hub bearing meets OE specification 3104102XGW01A and features a 5-bolt flange with integrated ABS sensor for precise wheel speed signaling.
Specifications
| Parameter | Value |
|---|---|
| DH Code | DWH01393 |
| Part Number | 3104102XGW01A |
| Position | Rear Axle |
| Outer Diameter | 109.80 mm (4.323 inch) |
| Bolt Holes | 5 |
| Thread Size | M14 x 1.5 |
| ABS Sensor | Integrated |
Note: Dimensional data is based on available sources. Please verify measurements against your original bearing before ordering.
Important: All information on this page is for reference only. Please verify OE numbers, dimensions, and vehicle fitment against your original part before ordering. Contact us for fitment confirmation.
DH Code & OE Numbers & Reference Numbers
DH Code: DWH01393
OE Numbers: 3104102XGW01A, 3104101XGW01A
Reference Numbers (Interchange):
Z90030R: 3104102XGW01A
9400695: 3104102XGW01A
9328044: 3104102XGW01A
Vehicle Fitment
HAVAL: Big Dog, Dargo
HAVAL: H6, F7x, Shenshou
Note: This bearing is designed for rear axle applications with 5-bolt flange and integrated ABS sensor. Verify your vehicle’s configuration before ordering.
Please verify OE number, dimensions and vehicle configuration before ordering.
Product Features
- Rear wheel hub bearing engineered specifically for Haval Big Dog and compatible models
- Third-generation hub unit design with integrated ABS sensor and 5-bolt flange
- Double-row ball bearing design provides stable load distribution for SUV applications
- Precision roll-formed design ensures consistent and optimized factory-installed preload, minimizing excessive noise and wear
- Application-specific advanced raceway designs reduce stress, rotation and heat on components, extending service life
- Triple rubber seal design with stainless steel and NBR blocks mud, water and dust
- Coated wheel bolts effectively prevent rust, ensuring smooth disassembly and accurate torque
- Manufactured in ISO/TS 16949 certified facilities with 100% product inspection
- Factory-sealed and pre-lubricated – no routine maintenance required
Installation Notes
- Verify the OE number on your original bearing matches 3104102XGW01A before installation
- Confirm rear axle fitment for your specific Haval Big Dog or compatible model
- This bearing includes integrated ABS sensor – verify your vehicle has ABS configuration
- This is a third-generation hub assembly – install as a complete unit, do not attempt to disassemble
- Check 5-bolt flange pattern with M14 x 1.5 threads matches your vehicle’s hub
- Clean the hub mounting surface thoroughly before fitting the new assembly
- Use a proper hydraulic press or hub installer – do not strike the bearing directly with a hammer
- Torque the axle nut to Haval service manual specifications; over-torquing can shorten bearing life
- After installation, check ABS sensor clearance and rotate the hub to ensure smooth operation
