3104100KZ16 Wheel Hub Bearing For GREAT WALL
The DUHUI 3104100KZ16 wheel hub bearing is a direct-fit rear axle replacement designed for Great Wall Haval H6 2WD models from 2012 to 2020. This rear wheel hub bearing meets OE specifications 3104100KZ16, 3104100KZ16A and DAC2F82R4527A, and features a 5-bolt flange with integrated ABS sensor for precise wheel speed signaling.
Specifications
| Parameter | Value |
|---|---|
| DH Code | DWH0851 |
| Part Number | 3104100KZ16 |
| Position | Rear Axle |
| Bolt Holes | 5 |
| ABS Sensor | Integrated |
| Bearing Generation | 3rd Generation Hub Unit |
| Bearing Material | GCr15 (SAE52100) Chrome Steel |
| Flange Material | 55# Steel |
| Cage Material | PA66+GF25 |
| Seal Material | Stainless Steel + NBR |
| Wheel Stud Grade | 10.9 |
| Bearing Rings Hardness | 60-65 HRC |
| Ball/Roller Hardness | 61-66 HRC |
| Race Surface Roughness (max) | ≤0.20 μm |
| Race Roundness (max) | ≤3 μm |
| Product Inspection | 100% |
| Quality Guarantee | 2 Years / 60,000 km |
Note: Dimensional data is based on available sources. Please verify measurements against your original bearing before ordering.
Important: All information on this page is for reference only. Please verify OE numbers, dimensions, and vehicle fitment against your original part before ordering. Contact us for fitment confirmation.
DH Code & OE Numbers & Reference Numbers
DH Code: DWH0851
OE Numbers: 3104100KZ16, 3104100KZ16A, DAC2F82R4527A
Reference Numbers (Interchange):
TRULY0665: 3104100KZ16A, DAC2F82R4527A
WH310595: DAC2F82R4527A, 3104100KZ16, 3104100KZ16A
Vehicle Fitment
GREAT WALL / HAVAL: H6 2WD (2012-2020)
Note: This bearing is designed for 2WD models with rear axle configuration and 5-bolt flange with integrated ABS sensor. Verify your vehicle’s drive configuration before ordering.
Please verify OE number, dimensions and vehicle configuration before ordering.
Product Features
- Rear wheel hub bearing engineered specifically for Great Wall Haval H6 2WD and compatible models
- 3rd generation hub unit design with 5-bolt flange and integrated ABS sensor for simplified installation and precise wheel speed signaling
- Double-row ball bearing design provides stable load distribution for SUV applications
- Precision roll-formed design ensures consistent and optimized factory-installed preload, minimizing excessive noise and wear
- Application-specific advanced raceway designs reduce stress, rotation and heat on components, extending service life
- Triple rubber seal design with stainless steel and NBR blocks mud, water and dust
- Coated wheel bolts effectively prevent rust, ensuring smooth disassembly and accurate torque
- Manufactured in ISO/TS 16949 certified facilities with 100% product inspection
- Factory-sealed and pre-lubricated – no routine maintenance required
Installation Notes
- Verify the OE number on your original bearing matches 3104100KZ16 before installation
- Confirm rear axle fitment for your specific Haval H6 2WD model (2012-2020)
- This bearing is designed for 2WD models – verify your vehicle’s drive configuration before ordering
- This bearing includes integrated ABS sensor – verify your vehicle has ABS configuration
- This is a 3rd generation hub assembly – install as a complete unit, do not attempt to disassemble
- Check 5-bolt flange pattern matches your vehicle’s hub
- Clean the hub mounting surface thoroughly before fitting the new assembly
- Use a proper hydraulic press or hub installer – do not strike the bearing directly with a hammer
- Torque the axle nut to Great Wall service manual specifications; over-torquing can shorten bearing life
- After installation, check ABS sensor clearance and rotate the hub to ensure smooth operation
About DUHUI Bearing
Manufactured by DUHUI Bearing – an automotive bearing supplier established in Zhejiang, China, in 2003. DUHUI produces wheel hub bearings to OE specifications. Contact us
