23866120 Wheel Hub Bearing For Wuling Sunshine Chevrolet BAIC
The DUHUI 23866120 wheel hub bearing is a direct-fit rear axle replacement designed for Wuling Sunshine, Chevrolet N200, and BAIC Weiwang 205 models. This rear wheel hub bearing meets OE specifications 23866120, 25410172 and 35016L, and features an integrated ABS sensor ring for precise wheel speed signaling.
Specifications
| Parameter | Value |
|---|---|
| DH Code | DWH01233 |
| Part Number | 23866120 |
| Position | Rear Axle |
| Flange Diameter | 120.00 mm (4.724 inch) |
| Inner Diameter | 28.00 mm (1.102 inch) |
| Bolt Holes | 4 |
| Bolt Thread Size | M12 x 1.5 |
| ABS Sensor | Included (with ABS) |
Note: Dimensional data is based on available sources. Please verify measurements against your original bearing before ordering.
Important: All information on this page is for reference only. Please verify OE numbers, dimensions, and vehicle fitment against your original part before ordering. Contact us for fitment confirmation.
DH Code & OE Numbers & Reference Numbers
DH Code: DWH01233
OE Numbers: 23866120, 25410172, 35016L, 24533069
Reference Numbers (Interchange):
GSPAT: 23866120
WULING: 35016L
Vehicle Fitment
WULING: Sunshine (with ABS)
CHEVROLET: N200 (with ABS)
BAIC: Weiwang 205 (with ABS)
Please verify OE number, dimensions and vehicle configuration before ordering.
Product Features
- Rear wheel hub bearing engineered for Wuling Sunshine, Chevrolet N200 and BAIC Weiwang 205 models
- 4-bolt flange design with M12 x 1.5 thread specification for secure wheel attachment
- Integrated ABS sensor ring for precise wheel speed signaling – compatible with factory ABS systems
- Precision roll-formed design ensures consistent and optimized factory-installed preload, minimizing excessive noise and wear
- Application-specific advanced raceway designs reduce stress, rotation and heat on components, extending service life
- Manufactured in ISO/TS 16949 certified facilities with 100% product inspection
- Factory-sealed and pre-lubricated – no routine maintenance required
Installation Notes
- Verify the OE number on your original bearing matches 23866120, 25410172, or 35016L before installation
- Confirm rear axle fitment for your specific Wuling Sunshine, Chevrolet N200, or BAIC Weiwang 205 model
- This bearing includes ABS sensor – verify your vehicle has ABS configuration
- Check 4-bolt flange pattern with M12 x 1.5 threads matches your vehicle’s hub
- Clean the hub mounting surface thoroughly before fitting the new assembly
- Use a proper hydraulic press or hub installer – do not strike the bearing directly with a hammer
- Torque the axle nut to manufacturer service manual specifications; over-torquing can shorten bearing life
- After installation, check ABS sensor clearance and rotate the hub to ensure smooth operation
About DUHUI Bearing
Manufactured by DUHUI Bearing – an automotive bearing supplier established in Zhejiang, China, in 2003. DUHUI produces wheel hub bearings to OE specifications. Contact us
