1014020154 Wheel Hub Bearing For Geely
The DUHUI 1014020154 wheel hub bearing is a direct-fit rear right axle replacement designed for Geely GX7, SX7, and Emgrand X7 2WD models. This rear wheel hub bearing meets OE specifications 1014020154 and 9326080, and features a 5-bolt flange with integrated 48-tooth ABS sensor ring for precise wheel speed signaling.
Specifications
| Parameter | Value |
|---|---|
| DH Code | DWH01219 |
| Part Number | 1014020154 |
| Position | Rear Right |
| Outer Diameter | 152.00 mm (5.984 inch) |
| Bolt Circle | 114.30 mm (4.500 inch) |
| Bolt Holes | 5 |
| Input Shaft Teeth | 26 |
| ABS Sensor | Included (48 teeth tone ring) |
Note: Dimensional data is based on available sources. Please verify measurements against your original bearing before ordering.
Important: All information on this page is for reference only. Please verify OE numbers, dimensions, and vehicle fitment against your original part before ordering. Contact us for fitment confirmation.
DH Code & OE Numbers & Reference Numbers
DH Code: DWH01219
OE Numbers: 1014020154, 9326080
Reference Numbers (Interchange):
GEELY: 1014020154, 9326080
Vehicle Fitment
GEELY: Gleagle GX-7 2WD (rear right)
GEELY: Emgrand X7 2WD (rear right)
GEELY: Gleagle SX7 2WD (rear right)
Note: This is the right-hand (passenger side) rear hub bearing for 2WD models. Verify your vehicle’s side and drive configuration before ordering.
Please verify OE number, dimensions and vehicle configuration before ordering.
Product Features
- Rear right wheel hub bearing engineered specifically for Geely GX7, SX7, and Emgrand X7 2WD models
- 5-bolt flange with 114.3mm bolt circle for secure wheel attachment
- Integrated 48-tooth ABS sensor ring for precise wheel speed signaling – compatible with factory ABS systems
- 26-spline input shaft for accurate drivetrain connection
- Precision roll-formed design ensures consistent and optimized factory-installed preload, minimizing excessive noise and wear
- Application-specific advanced raceway designs reduce stress, rotation and heat on components, extending service life
- Manufactured in ISO/TS 16949 certified facilities with 100% product inspection
- Factory-sealed and pre-lubricated – no routine maintenance required
Installation Notes
- Verify the OE number on your original bearing matches 1014020154 or 9326080 before installation
- Confirm this is the right-hand (passenger side) rear axle for your specific Geely model
- This bearing is designed for 2WD models – verify your vehicle’s drive configuration before ordering
- This bearing includes ABS sensor – verify your vehicle has ABS configuration
- Check 5-bolt flange pattern with 114.3mm bolt circle matches your vehicle’s hub
- Clean the hub mounting surface thoroughly before fitting the new assembly
- Use a proper hydraulic press or hub installer – do not strike the bearing directly with a hammer
- Torque the axle nut to Geely service manual specifications; over-torquing can shorten bearing life
- After installation, check ABS sensor clearance and rotate the hub to ensure smooth operation
About DUHUI Bearing
Manufactured by DUHUI Bearing – an automotive bearing supplier established in Zhejiang, China, in 2003. DUHUI produces wheel hub bearings to OE specifications. Contact us
